Overview

The JTHX Series is an advanced Cartesian desktop robotics platform designed for applications that demand specialized vertical precision. Unlike the JTHD series, the JTHX utilizes a distinct Z-axis architecture and a specialized servo motor configuration. While this results in a slightly lower maximum X/Y Point-to-Point velocity (500 mm/s), it ensures exceptional dynamic stability and smooth Continuous Path generation. Available in effective work areas ranging from 150x150mm to 450x450mm, the JTHX is optimized for complex 3D routing, precision dispensing, and automated assembly tasks.

Key Benefits

• Specialized Servo Dynamics: Distinct servo motor tuning prioritizes smooth, consistent motion profiles over raw X/Y speed, crucial for high-quality fluid dispensing and soldering.
• Optimized Vertical Stability: A specialized Z-axis design provides enhanced rigidity, ensuring tool accuracy remains uncompromised during rapid downward actuation or lateral resistance.
• Continuous Path Excellence: Achieves CP speeds of up to 500 mm/s with full 3D linear and arc interpolation, maintaining ±0.01 mm repeatability throughout the entire tool path.
• Integrated Workcell Solution: Out-of-the-box compatibility with the TSC400 provides intuitive PC-based teaching, rapid 2D CAD-to-path conversion, and robust I/O handling.

Target Applications

• Precision Dispensing: High-quality application of adhesives and sealants where smooth motion is prioritized over maximum point-to-point speed.
• Automated Soldering: Repeatable, heat-controlled soldering of PCB components utilizing the platform's stable continuous path capabilities.
• Automated Routing: Desktop-scale routing and material removal tasks that benefit from enhanced Z-axis rigidity.
• Electronics Assembly: Reliable component sorting, pressing, and handling in tight desktop manufacturing environments.
